NEXUS 8.5KVA DIESEL 1PH SILENT GENERATOR
$3,295.00
NEXUS 8.5KVA DIESEL 1PH SILENT GENERATOR
2 in stock
Description
Description
NEXUS 8.5KVA DIESEL 1PH SILENT GENERATOR
Specifications
| Model | NX12STA | ||||
Generator set | Rated frequency | Hz | 50 | ||
Rated Power | kVA | 8.5 | |||
| kW | 8.5 | ||||
Max.power | kVA | 9.5 | |||
| kW | 9.5 | ||||
| Rated voltage | V | 115/230 | |||
| Rated current | A | 73.9/37 | |||
| Rated rotation speed | r/min | 3000 | |||
Alternator | Generator Model | KT12 | |||
| pole | 2 | ||||
| phase number | Single Phase | ||||
| Excitation mode | Self-excitation and constant voltage (AVR) | ||||
| Power factor | cosΦ | 1.0 | |||
| Insulation grade | F | ||||
Engine | Engine model | RD2V80 | |||
| Sturcture type | V-twin, 4-stroke, swirl type, water-cooled | ||||
| Boke x stroke | mm | 80×79 | |||
| Displacement | mL | 794 | |||
| Compression ratio | 23:1 | ||||
| Rated power | kW | 12.5 | |||
| Lubrication system | Pressure splashed | ||||
| Lube oil brand | Above CD grade or SAE 10W-30, 15W-40 | ||||
| Lube capacity | L | 2.27 | |||
| Starting system | Electric starter | ||||
| Charging genrator capacity | 12V 36Ah | ||||
| Fuel consumptioon ratio | 285 | ||||
| Fuel type | Diesel： 0＃(Summer)-10＃(Winter)-35＃(chillness) | ||||
Genset | Panel type | Digital panel | |||
Output | Receptacle | two single-phase receptacles | |||
Connection pole | available | ||||
DC12V output | NA | ||||
| Noise level (7m) | dB/A | 72 | |||
| Fuel tank capacity | L | 26 | |||
| Overall dimension (L*W*H) | mm | 1350×650×760 | |||
| Net weight | kg | 310 | |||
Packing | Package | plywood case | |||
| Dimension (L*W*H) | mm | 1445×715×875 | |||
| Gross Weight | kg | 325 | |||
