MODEL |
PV18-3024PRO |
PV185-5248 PRO |
|
|
Nominal Battery System Voltage |
24VDC |
48VDC |
|
|
INVERTER OUTPUT |
Rated |
3000VA/3000W |
5200VA/5200W |
|
Surge |
6000W |
10400W |
|
|
Waveform |
Pure Sine |
Pure Sine |
|
|
AC |
230VAC±5%(Setting) |
230VAC±5%(Setting) |
|
|
Inverter |
93% |
93% |
|
|
Transfer |
10ms |
10ms |
|
|
AC INPUT |
Voltage |
230VAC±5% |
230VAC±5% |
|
Selectable |
170-280VAC(UPS) |
170-280VAC(UPS) |
|
|
BATTERY |
Frequency |
|
|
|
Normal |
24VDC |
48VDC |
|
|
Floating |
27.4VDC |
54.8VDC |
|
|
Overcharge |
30VDC |
60VDC |
|
|
SOLAR CHARGER & AC CHARGER |
Maximum |
450VDC |
450VDC |
|
Maximum |
18A |
18A |
|
|
PV Array |
150-430 VDC |
150-430 VDC |
|
|
Maximum |
80Amp |
80Amp |
|
|
Maximum |
60Amp |
60Amp |
|
|
Maxumum Charge Current |
80Amp |
80Amp |
|
|
Charge |
MPPT |
MPPT |
|
|
MECHANICAL SPECIFICATIONS |
Machine |
272*355*100 |
295*528*121 |
|
Package |
540*395*241 |
328*425*251 |
|
|
Net |
11 |
14 |
|
|
Gross |
12 |
15 |
|
|
OTHER |
Humidity |
5% to 95% Relative Humidity (Non -condensing) |
5% to 95% Relative Humidity (Non -condensing) |
|
Operating |
0°C – 50°C |
0°C – 50°C |
|
|
Storage |
-15°-60°C |
-15°-60°C |
|
